MELAMINE FACED PANELS

MODEpan Thermo-fused Melamine faced Pre-laminated MDF / Chipboard Panels, these are excellent Materials For Horizontal and vertical surfaces and designed for the new age is Available in a standard size of 1220 * 2440mm and thickness from 3mm to 25mm.

MODEpan panels are used by the furniture industry for all types of Home, office furniture and other interior and architectural Work

BROWSE TEXTURE

BROWSE COLORS

DATA SHEET FOR MELAMINE FACED PANELS

Product Name : MODE pan
Size : 3.0mm to 25.0mm x 1220mm x 2440mm
Product specifications
Thickness 3 – 25 mm
Thickness Tolerance +0.5 mm / -0.3 mm
Length 2440
Length tolerance ± 5 mm
Width 1220 mm
Width tolerance ± 5 mm
Edge chipping ≤ 5 mm
Available textures Matt , Pearl , Nature Touch, Ash wood
Technical Specifications as Per EN 14322 Colors Without MODEshield Colors With MODEshield
Resistance To wear

• Taber cycles AP
• Index As per EN 14322



50
1



≥350
3

Resistance to scratch

• Load in Newton



≥2.5



≥ 3

Resistance To steam No visible change -5
Resistance to cracking No crack -5
Resistance to staining No effect – 5
Resistance to cigarette burns Slight change – 4
